| Parameter Item | Nominal Value | Tolerance | Unit |
| Wire Diameter | 14.0 | ±0.15 | mm |
| Outer Diameter | 166.0 | ±1.5 | mm |
| Inner Diameter | 138.0 | ±1.5 | mm |
| Free Length | 375.0 | ±3.0 | mm |
| Total Coils | 5.8 | ±0.25 | Coils |
| Active Coils | 4.6 | ±0.25 | Coils |
| Direction | Right-hand | — | / |
| End Type | Closed & Ground Flat | — | / |
| Spring Rate | 375 | ±4.0% | N/mm |
| Hardness | 47–49 | ±2 | HRC |
OEM Part Number:54630-2D010
Replaced by: 54630-2D010-DS (Latest Revision)
Alternate OE: 54630-2D010, 54630-2D011
Product Name: Front Suspension Coil Compression Spring
Application: Hyundai Elantra (XD) 2001–2005 4-door Sedan
Position: Front Axle, Left & Right Universal
Marking: Blue identification mark
Fitment Note: Manual transmission, without A/C
Weight: 3.15 kg (6.94 lbs)
Material: 60Si2Mn / SUP10 High Strength Spring Steel
Quality Standard: ISO/TS16949, JIS G 4801
Recommended Replacement: Replace in pairs (LH+RH)
Warranty: 1 Year / 100,000 km
